Compare industrial inspection cameras side by side to find the right tool for you.
Product Comparison
Feature Comparison Tables for Boroscopes, Sewer Cameras and Video Scopes
Comparison of Pipe Cameras
| Setup | MiniFlex | Viper | Trogloprobe | Anaconda | Hathorn |
|---|---|---|---|---|---|
| Working Length, ft. | 65.6 - 131ft. | 65.6ft. - 196.8ft. | 298ft. | 197ft. - 393.7ft. | Up to 500ft. |
| Pipe Diameter | 1” - 8” | 0.3” - 6”* | 1.5” - 24”* | 3” - 24”* | 1.5” - 12”* |
| Maneuverability | +++++ | +++ | + / ++++* | + | ++++ |
| Grade | Commercial | Consumer | Commercial | Consumer | Commercial |
| Camera Head | Axial | Axial | Axial / Pan-Tilt* | Dual / Pan-Tilt* | Axial |
Comparison of Borescope Cameras
| Setup | No Tip Articulation | 2-way Tip Articulation | 4-way Tip Articulation | |
|---|---|---|---|---|
| Below 2.0mm | MICRON / VOYAGER C40 | |||
| 2.4mm Probe | MICRON | XLED PRO | VOYAGER C40 | |
| 2.8mm Probe | / | XLED PRO | VOYAGER C40 | |
| 4.0mm Probe | IRIS PRO | IRIS PRO | IRIS PRO / XLED PRO / ILED PRO / VOYAGER C40 / C50 | |
| 5.5mm and Up | IRIS PRO | IRIS PRO | IRIS PRO / XLED PRO / ILED PRO / VOYAGER C40 / C50 |
Comparison of Fiber Optic Borescopes
| Setup | Min. Diameter | Max. length |
|---|---|---|
| NON-ARTICULATING | ||
| UltraFine Micro Borescope | 0.37mm (0.0146") | 610mm (24") |
| ARTICULATING | ||
| IFlex/EF Fiberscope | 2.4mm (0.094”) | 1300mm (51") |
Comparison of Small Diameter Video Borescopes with CMOS Sensor
| Setup | Min. Diameter | Max. length |
|---|---|---|
| NON-ARTICULATING | ||
| MICRON USB Borescope | 1.0 mm | 2000 mm (78.7”) |
| VOYAGER Borescope Camera C40 | 1.2mm | 1000mm (39") |
| ARTICULATING | ||
| VOYAGER Borescope Camera C40 | 2.0 mm | 3000 mm (118.1”) |
| XLED PRO Industrial Videoscope | 2.4 mm (0.094”) | 3000 mm (118.1”) |
Long Borescopes with Non-Articulating Tip
| Setup | Length | Sheeting | Articulation | Cost / Grade |
|---|---|---|---|---|
| VOYAGER C40 option | 15m (49') | Tungsten | No, side-view camera available | ★★★★ |
| IRIS option | 20m (65.6') | Tungsten | No, side-view camera, or prizm available | ★★★★★ |
Long Borescopes with 2- and 4-way tip articulation
| Setup | Length | Sheeting | Articulation type | Cost / Grade |
|---|---|---|---|---|
| VOYAGER C40 | 10m (32.8’) | Tungsten | All-way, Mechanical | ★★★★ |
| VOYAGER C50 | 10m (32.8’) | Tungsten | All-way, Motorized | ★★★★ |
| IRIS PRO | 10m (32.8’) | Tungsten | 4-way, Mechanical | ★★★★★ |
| IRIS XTC | 15m (49') | Tungsten | 4-way, Mechanical | ★★★★★ |
Pipe Robots Comparison Chart
| Setup | SIGMA HD-LR | SIGMA-HD | STORMER | TROGLOTREK | |
|---|---|---|---|---|---|
| Working length | up to 6,500 ft | up to 1,640 ft | 820 ft | 980 ft | |
| Min and Max Pipe Diameters | 14” - 120” | 8” - 120” | 6” - 40” | 4” - 40” | |
| Power source | Battery/External | External | External | Battery | |
| Front camera | Full 1080p HD, Pan-Tilt-Zoom, Optical vibration stabilization, Manual focus | Full 1080p HD, Pan-Tilt-Zoom, Optical vibration stabilization, Manual focus | Pan-and-tilt,Manual focus | Pan-and-tilt, Manual focus | |
| Rear-view camera | Yes, Full 1080p HD | Yes, Full 1080p HD | No | Yes | |
| Front camera riser | No | Yes, Remotely operated | Yes, Manual | No | |
| Pipe plotting and measuring | Yes, Laser | Yes, Laser | No | Comparative measuring | |
| Steering | Yes | Yes | No | Yes | |
| Tether reel type | Motorized or Manual | Motorized or Manual | Manual | Motorized | |
| Extra Features | Sonde,Rollover protection,Inclinometer,Internal pressure monitor,Gyroscope Wheels/Tracks | Sonde,Rollover protection,Inclinometer,Internal pressure monitor,Gyroscope Wheels/Tracks | Inclinometer, Wincan compatible,Wheels of different diameter | Inclinometer, Wincan compatible,Wheels of different dia.Sonde (optional) | |
| Submersible | Yes | Yes | Yes | Yes | |
| Preinstalled reporting software | Yes | Yes | No | No |
Need specific inspection gear to match your requirements? Spend a few minutes with our technical sales specialists: their years of experience finding solutions can help you find the most efficient inspection tool to achieve the results you want, for the budget you need.
