Borescopes for Weld Inspection and Quality Control
The quality of welds is becoming increasingly important as customer expectations rise. Products and components are expected to be high quality and not to fail unexpectedly. Such failures have large financial and social consequences which can be avoided with proper inspection techniques, and tools.
Inspecting welds directly can reduce costs by detecting defects in earlier stages of manufacturing, reducing the cost of customer returns and extending the life of the components by correcting them.
Nondestructive testing (NDT) is one method used to ensure the integrity of structural welds in steel, aluminum and titanium. NDT can be used to identify cracks, incomplete penetration, inclusions, incomplete sidewall fusion, leaks, and similar defects, which can compromise the strength of your welds. Portable borescopes are key to quickly and easily inspecting welds, and can offer full image and video documentation and storage. The quality and color of the weld bead, as well as residual deposits on the welding can be visually inspected with our color videoscopes, and their smooth coated insertion probes are designed to prevent polished pipes from surface scratches.
Probe
- Ø 2.8mm (0.110") to 16mm (0.629”)
- Working Lengths from 1 meter (3.3') up to 30 meters (98')
- Fast (30 fps), high resolution CMOS video camera chip
- Camera Chip Resolution: 4mm - 100,000/5.5mm and up - 450,000 pixel
- Optional Mirror Tips for Ø5.5mm Probes: 70° / 90° / 110°
- 3.5” color LCD display, with 720x640 pixel resolution
- Image (JPEG )/Video (MPEG4) file capture
- Variety of imaging options including grid, mirror functions, zoom-in/zoom-out
- AV output (PAL/NTSC selectable)
- SD memory card for file capture/storage
- USB port to transfer data to a PC
- LED Illumination, with variable intensity adjustment
- Working temperature -20° to +60°
- Compact portable design
Probe
- 4-Way, 360 Degree Joystick Controlled Manual Articulation
- 720P HD Resolution
- 3.2ft. - 22.9ft. (1.0m - 7.0m) Working Length
- Ø 0.08" (2.2mm), 0.11" (2.8mm), 0.15" (3.9mm) and 0.23" (6mm) Probes Available
- IP67 Waterproof, Tungsten Braided Insertion Probe
- interchangeable Insertion Probes Can Be Changed in Seconds
- Pistol Grip Design with Magnetic Stand
- High-Output White LED Lights (Optional IR LED's Available)
- Adjustable Illumination
- Integrated 3.5” Sony TFT LCD Monitor
- USB Connection
- micro SD Card Slot
- Image and Video File Capture
- Samsung Li-Ion Rechargeable Battery for Portable Use
Probe
• Ø 0.5mm (0.02") probe diameter
• Working Length - 250mm (9.8")/ 500mm (19.7")/ 1000mm (40")
• German made optics
• High Resolution Quartz Fiber optic Image bundle
• Low image leakage due to the optimal size of the fibers
• Built in focus ring on eyepiece
• Detachable strain relief
• 32mm DIN universal eyepiece
Probe
• Stainless Steel Braided Probe Ø 4.0 mm (0.15in), 6.0 mm (.23in) or 8.0 mm (0.315in)
• 2-way, 90 degree, tip articulation
• Working Length: 110cm (43.3 in)/160cm (63 in)
• 12,000/ 20,000 pixel fiber optic image bundle
• Specialized light post
• Universal focusable eyepiece
Probe
- Advanced Fiber Optic Camera Videoscope
- Comparative measurement function
- 5’’ high-resolution VGA display
- Powerful LED light illumination with fiberoptics and 3 step light intensity control
- Excellent image quality
- Camera Control / Exposure Integration modes: Automatic, Short, Long, Manual
- Horizontal and vertical image inversion
- Integrated interchangeable direct view/side view lens
- 180° rotating screen and a 180° rotatable ergonomic handle
- Heat resistant videoprobes
- Different working lengths of probes up to 7.5 m(24.6 ft)
- Variable videoprobe diameters: 4.0 mm, 6.0 mm, 8.0 mm
- Tactile videoprobe contact in the inspection object
- Extra-durable Tungsten Braided probes
- Liquid tight probe up to 1 bar
- Video (.avi) and Still-images (.bmp) recording
- 3.5x zoom
- 4-way 360° Tip articulation control
Probe
- Extremely durable tungsten-braided probe
- Working length of probes: 4.9 – 13.1 ft (1.5 – 4.0 m), 4.9 - 24.6 ft (1.5 – 7.5 m)
- Diameter: 3mm (0.118"), 4mm (0.157") and 6mm (0.236"), 8mm (0.314")
- High-resolution camera integrated in a short rigid distal end
- Capacity to measure problem areas
- Large integrated display (5.0“/12.7 cm) with VGA 640x480 resolution
- Probe and distal end are water-proof up to 14.7 psi
- State of the art “chip on the tip” image sensor
- 3.5x zoom
- 3-stage adjustable LED illumination
- 4-way tip articulation with 360° rotation (2-way for 3mm probe)
- Rechargeable 6h battery
- 32,000 images or 500 hours of video can be stored on 32GB SDHC card
- Direct action keys and on-screen menu
- Light, portable, robust, durable Video Scope
Probe
- Camera Head Diameter: 12mm (0.47”), 16mm (0.63”)
- CMOS Sensor Resolution: 450,000 pixels
- Probe Type: Flexible / Flex-and-Stay
- Probe Lengths: 1-3 meters (3.28’ – 9.84’)
- DOF: 80mm-infinity (3.15”-infinity)
- Light Source: 2 or 4 Extra Bright LEDs
- Waterproof
Base:
- 3.5” Color LCD Display: 720x640 pixels
- Image (JPEG )/Video (MPEG4) file capture
- Zoom and Grid Features
- AV output (PAL/NTSC selectable) - on request
- SD card for capturing data
- USB port for data transfer
Upgraded version of this model available here: http://www.fiberscope.net/orion-video-borescope.html
Probe
- Stainless Steel Insertion Probes
- CMOS Video Camera Chip: 450,000 pixels
- Insertion Probe Diameter 6.5mm
- 3.5” Colour LCD Display, with 720x640 pixels
- Image (JPEG )/Video (MPEG4) File Capture
- AV Output (PAL/NTSC selectable)
- SD Memory Card for File Storage
- USB port to transfer data to a PC or Laptop
- Adjustable LED Illumination
- Interchangeable Probes (Optional Articulating, Side and Straight View)
- Detachable Handle/Base
- Waterproof Probe: IP 57
- Working Lengths: 300 mm (11.8"), 450 mm (17.7"), 700mm (27.5")
Probe
- 2- and 4-way Tip Articulation
- Narrow Diameter, from 2.4mm (0.094 inch) Probes
- Ultra Short Articulating Tip
- FOLED Hybrid Illumination, with up to 5000 hours of Lamp Life
- Waterproof Tungsten Braiding
- Advanced High Resolution CMOS Image Sensor
- Intelligent Image Enhancement Control
- Optional 7“ Touch Screen Display
- Optional Direct Connection to Computer
- Excellent Price-Performance Ratio
- Robust and Durable, Supplied Ready to Work
- Designed and Manufactured in Germany
