The Nanoray Micro Video Borescope offers outstanding clarity for detailed inspections, even in the tightest spaces. With ultra-thin insertion probes available in 1mm and 1.6mm diameters and lengths of 1m and 2m, this device is designed for precision. It features a high-resolution 160,000-pixel CMOS sensor paired with sufficient LED illumination, delivering vivid and detailed visuals. The user-friendly 6" tablet allows for real-time viewing, along with easy image and video capture.
MICRO Videoscope NANORAY X35
Price
Prices are subject to change. To find out the exact price of the set, write or call us.
Precision Engineering for Challenging Inspections
The Nanoray Micro Video Borescope combines cutting-edge technology with thoughtful design to deliver unparalleled inspection capabilities.
Micro Video Borescope NANORAY X35 Intro
Specifications
-
Ultra-Thin ProbesAvailable in diameters from 1 mm, access spaces that other inspection tools simply cannot reach. -
High-Resolution ImagingEquipped with a 160,000-pixel CMOS sensor that captures detailed images. -
6" Integrated TabletView, Capture, Playback, or Transfer the Inspection Data -
LED Illumination SystemIntegrated LED lighting provides sufficient illumination in dark spaces.
- Probe Diameters: 1mm, 1.6mm, and 1.8mm options
- Probe Length: 3.2ft (1m) and 6.5ft (2m) options
- Image Sensor: 160,000-pixel CMOS
- Illumination: Integrated LED system
- Display: 6" touch-screen tablet
- Media Capture: Image and video recording
- Interface: Intuitive touch controls
- Power Source: Rechargeable battery
Available Insertion Tube Exteriors
Features
1.8mm
1.6mm
1.0mm
Tungsten braid
Metal spring
Medical TPU
Silicon ABS
In the Box
Control Unit
Insertion Probe
HDMI Cable
Battery charger
Tell us about your application, and we will recommend you the right tool to do the job!
Full Description
The NANORAY X35 Micro Video Borescope is a purpose-built inspection system for engineers who must uncover microscopic defects in the most confined and hostile environments without sacrificing speed or traceability.
At its core is a 160-thousand-pixel CMOS imaging sensor paired with an integrated LED array that delivers true-colour, high-definition visuals powerful enough to expose hairline fissures inside refinery pipelines, turbine cooling passages, or micro-welds. The micro-diameter probes — 1 mm, 1.6 mm, and 1.8mm — are available in 3.2ft (1m) and 6.5ft (2m) lengths, giving operators the reach to navigate complex geometries while eliminating costly disassembly.
A six-inch touchscreen tablet with a convenient stand anchors the X35’s user experience. Operators can pinch-to-zoom, tap to capture photos or video, annotate on the spot, and organise findings in intuitive folders without leaving the inspection site. The software suite timestamps every frame, generates ready-to-send reports, and lets users overlay reference images for instant before-and-after comparisons, turning raw footage into actionable maintenance data in minutes.
Recognising that no single insertion tube can handle every task, we designed the NANORAY X35 micro video borescope around a fully interchangeable, quick-connect probe architecture. The standard tungsten-braided tube shrugs off abrasion inside rough castings; a spring-coil variant bends effortlessly through serpentine corridors; a medical-grade smooth tube glides across delicate surfaces without leaving a mark; and an ABS silicon option is more resistant to aggressive chemicals and elevated temperatures. All tubes are IP67 rated, ensuring reliable operation in dusty or wet environments.
Collaboration is equally uncompromised. The X35 streams live HD video to remote experts or casts inspections onto large screens so entire teams can diagnose problems in real time, cutting downtime and travel costs alike. A high-capacity rechargeable battery powers an entire shift, and hot-swap spares keep the scope online for round-the-clock operations.
Whether reducing weld-inspection cycles in petrochemical refineries, catching early pitting in wind turbine gearboxes, or compressing aircraft engine overhauls, the NANORAY X35 delivers microscopic clarity, modular adaptability, and frictionless data management in a single, field-ready package—transforming hidden risks into confident decisions faster than ever before.
Customizations available. Call for details.
NANORAY Micro Videoscope is a custom-ordered product.
At its core is a 160-thousand-pixel CMOS imaging sensor paired with an integrated LED array that delivers true-colour, high-definition visuals powerful enough to expose hairline fissures inside refinery pipelines, turbine cooling passages, or micro-welds. The micro-diameter probes — 1 mm, 1.6 mm, and 1.8mm — are available in 3.2ft (1m) and 6.5ft (2m) lengths, giving operators the reach to navigate complex geometries while eliminating costly disassembly.
A six-inch touchscreen tablet with a convenient stand anchors the X35’s user experience. Operators can pinch-to-zoom, tap to capture photos or video, annotate on the spot, and organise findings in intuitive folders without leaving the inspection site. The software suite timestamps every frame, generates ready-to-send reports, and lets users overlay reference images for instant before-and-after comparisons, turning raw footage into actionable maintenance data in minutes.
Recognising that no single insertion tube can handle every task, we designed the NANORAY X35 micro video borescope around a fully interchangeable, quick-connect probe architecture. The standard tungsten-braided tube shrugs off abrasion inside rough castings; a spring-coil variant bends effortlessly through serpentine corridors; a medical-grade smooth tube glides across delicate surfaces without leaving a mark; and an ABS silicon option is more resistant to aggressive chemicals and elevated temperatures. All tubes are IP67 rated, ensuring reliable operation in dusty or wet environments.
Collaboration is equally uncompromised. The X35 streams live HD video to remote experts or casts inspections onto large screens so entire teams can diagnose problems in real time, cutting downtime and travel costs alike. A high-capacity rechargeable battery powers an entire shift, and hot-swap spares keep the scope online for round-the-clock operations.
Whether reducing weld-inspection cycles in petrochemical refineries, catching early pitting in wind turbine gearboxes, or compressing aircraft engine overhauls, the NANORAY X35 delivers microscopic clarity, modular adaptability, and frictionless data management in a single, field-ready package—transforming hidden risks into confident decisions faster than ever before.
Customizations available. Call for details.
NANORAY Micro Videoscope is a custom-ordered product.
