Well cameras are the tool of choice for remote visual inspection and downhole surveys of vertical bores, shafts, geothermal and water wells. They are commonly used for routine or post-service assessments, condition evaluation, and monitoring. Whether you're a well contractor, pump installer, driller, or environmental professional, selecting the right camera system is essential for efficient and accurate inspections.
Borehole and Well Inspection Cameras
Best for Deep Wells and Geothermal Applications
STRAHL HDL Deep Well Camera
The STRAHL HDL is the ultimate solution for comprehensive deep borehole inspections. This motorized system features a high-definition, dual-view camera head with the highest pressure rating in our lineup, making it ideal for the most demanding inspection environments.
- Up to 500m (1,640ft) Working Length
- Motorized Cable Winch
- 50 Bar Waterproof Dual Cameras
- 13" HD IPS LCD Display
- Borehole Diameter Range 3" to 80"
Best for Deep Wells and Geothermal Applications
STRAHL HDL Deep Well Camera
The STRAHL HDL is the ultimate solution for comprehensive deep borehole inspections. This motorized system features a high-definition, dual-view camera head with the highest pressure rating in our lineup, making it ideal for the most demanding inspection environments.
- Up to 500m (1,640ft) Working Length
- Motorized Cable Winch
- 50 Bar Waterproof Dual Cameras
- 13" HD IPS LCD Display
- Borehole Diameter Range 3" to 80"
Best for Residential Well Inspections and General Boreholes
STRAHL HD Well Camera
The STRAHL HD is a professional-grade downhole camera system designed for comprehensive residential well inspections and general borehole surveys. With its dual-camera head and 360° endless panning capability, it delivers complete, high-contrast inspection footage.
- Reaches Down to 656 ft (200m) - 984 ft (300m)
- Manual or Motorized Cable Reels
- 30 Bar Waterproof Dual Cameras
- 13" HD IPS LCD Display
- Borehole Diameter Range 3" to 80"
Best for Residential Well Inspections and General Boreholes
STRAHL HD Well Camera
The STRAHL HD is a professional-grade downhole camera system designed for comprehensive residential well inspections and general borehole surveys. With its dual-camera head and 360° endless panning capability, it delivers complete, high-contrast inspection footage.
- Reaches Down to 656 ft (200m) - 984 ft (300m)
- Manual or Motorized Cable Reels
- 30 Bar Waterproof Dual Cameras
- 13" HD IPS LCD Display
- Borehole Diameter Range 3" to 80"
Best for Shallow Wells and Vertical Shafts
STRAHL PT Mini Downhole Camera
The STRAHL PT is an entry-level downhole camera designed for professionals who need reliable vertical inspection capabilities without the complexity and cost of deep-well systems. It bridges the gap between duct cameras and full-scale well inspection systems.
- Up to 360 ft (110m) Working Length
- Pan and Tilt Camera Head
- 8" HD IPS LCD Display
- Borehole Diameter Range 3" to 40"
Best for Shallow Wells and Vertical Shafts
STRAHL PT Mini Downhole Camera
The STRAHL PT is an entry-level downhole camera designed for professionals who need reliable vertical inspection capabilities without the complexity and cost of deep-well systems. It bridges the gap between duct cameras and full-scale well inspection systems.
- Up to 360 ft (110m) Working Length
- Pan and Tilt Camera Head
- 8" HD IPS LCD Display
- Borehole Diameter Range 3" to 40"
Best for Chimney and Duct Inspections
DUCT-SCAN Micro Downhole Camera
The DUCT-SCAN MICRO is a portable and compact inspection device specifically designed for vertical ductwork, chimneys, and flues. This camera excels in dry environments where water submersion is not required.
- Reaches Down to 65 ft (20m)
- Fully Portable
- Dual Lens Camera Head
- 8" HD IPS LCD Display
- Borehole Diameter Range 3" to 30"
Best for Chimney and Duct Inspections
DUCT-SCAN Micro Downhole Camera
The DUCT-SCAN MICRO is a portable and compact inspection device specifically designed for vertical ductwork, chimneys, and flues. This camera excels in dry environments where water submersion is not required.
- Reaches Down to 65 ft (20m)
- Fully Portable
- Dual Lens Camera Head
- 8" HD IPS LCD Display
- Borehole Diameter Range 3" to 30"
Choosing the Right Well Inspection Camera for Your Application
Choosing the proper downhole camera depends on three factors: inspection depth, environmental conditions, and your specific application. Our lineup of four specialized camera systems covers the full spectrum of vertical inspection needs, from shallow ductwork to deep geothermal wells.
Four Camera Systems for Every Inspection Depth
From Shallow Ducts to Deep Geothermal Wells — Choose the Right Tool for Your Application
DUCT-SCAN MICRO
Depth65 ft (20m)
CategoryShallowest
EnvironmentDry Only
STRAHL PT
Depth360 ft (110m)
CategoryShallow
EnvironmentIP68 (Wet)
STRAHL HD
Depth656ft / 984ft
CategoryDeep
Environment30 Bar
STRAHL HDL
Depth984ft / 1640ft
CategoryDeepest
Environment50 Bar
Application Suitability Guide
| APPLICATION | DUCT-SCAN | STRAHL PT | STRAHL HD656ft / 984ft | STRAHL HDL984ft / 1640ft |
|---|---|---|---|---|
| Chimney Inspection | Excellent | Possible | Not Suitable | Not Suitable |
| HVAC Ducts | Excellent | Excellent | Not Suitable | Not Suitable |
| Shallow Wells (<360ft) | Not Suitable | Excellent | Excellent | Possible |
| Residential Wells | Not Suitable | Not Suitable | Excellent | Excellent |
| Deep Wells (>1000ft) | Not Suitable | Not Suitable | Possible | Excellent |
| Residential Geothermal | Not Suitable | Not Suitable | Excellent | Possible |
| Deep Geothermal | Not Suitable | Not Suitable | Possible | Excellent |
| Underwater Use | Not Suitable | Possible | Excellent | Excellent |
Excellent
Possible
Not Suitable
Understanding Well Camera Components
The typical well camera consists of a camera head,
a reel with a flexible cable, and a control unit.
a reel with a flexible cable, and a control unit.
Camera Head
The camera head must be fully waterproof and metal-housed for durability. Extra-bright LED illumination is essential because inspections are performed without ambient light. Well inspection cameras can have one or two imaging sensors: one for forward viewing and another for panning observation of side walls.
Cable Reel
The winch can be either manual or motorized with a footage counter. The cable is reinforced with high breaking strength, waterproof, and flexible enough to navigate vertical drops smoothly. Cable length determines maximum inspection depth.
Control Unit
The control unit provides a live color view of the inspection area and enables data capture and storage for further analysis. You can remotely operate the camera head by joysticks or navigation buttons. Additional features may include a keyboard for adding comments, Wi-Fi, temperature readings, and depth display.
Maximize your productivity with the right well camera. Our technical sales specialists are ready to assist you in choosing the system that will be a proper fit for your application and budget.
Deep (Borehole and Downhole) Cameras for Sale
General Information About Well Inspection Cameras
Well inspection cameras are special cameras used to inspect deep holes, such as water wells or mines, to see what is happening inside. The camera head is mounted on a flexible cable, which is lowered into the well. As the camera descends, it captures images and videos of the well's interior, which are transmitted to a monitor or recording device on the surface. This allows the operator to see a real-time view of the inside of the well and identify any problems that need to be addressed.
The equipment will be helpful if you need to get into vertical channels that are hard for people to reach and see things that are hard to see any other way. They are typically used to assess the condition of a well or mine and identify any issues that may be affecting its performance, such as blockages, cracks, fractures, or other types of damage.
Well inspection equipment is very rugged and can work underwater, in very wet or dirty areas, and have special illumination that allows you to see even in the dark. They can be used for various purposes, such as checking for damage or seeing if water or gas is coming into the well. Water well cameras are commonly used by well contractors, pump installers, drillers and other professionals in the industry.
The equipment will be helpful if you need to get into vertical channels that are hard for people to reach and see things that are hard to see any other way. They are typically used to assess the condition of a well or mine and identify any issues that may be affecting its performance, such as blockages, cracks, fractures, or other types of damage.
Well inspection equipment is very rugged and can work underwater, in very wet or dirty areas, and have special illumination that allows you to see even in the dark. They can be used for various purposes, such as checking for damage or seeing if water or gas is coming into the well. Water well cameras are commonly used by well contractors, pump installers, drillers and other professionals in the industry.
FAQ about underwater borehole inspection cameras
How does a downhole camera work?
The borehole camera is equipped with LED lights to illuminate the inspected area and has a panning dual-view camera to capture different angles and views of the well. The camera head is lowered into the borehole on the end of the cable. As the camera head descends, it captures images and videos of the surrounding area, which are transmitted to the control unit on the surface for analysis.
The data captured by the downhole camera is used to inspect the condition of the well or borehole, identify blockages or other obstructions, locate fractures or other damage, and monitor the progress of remedial work or drilling operations.
The data captured by the downhole camera is used to inspect the condition of the well or borehole, identify blockages or other obstructions, locate fractures or other damage, and monitor the progress of remedial work or drilling operations.
What is a downhole camera?
A well camera is a device used to inspect the inside walls of a well or borehole. It usually consists of a camera mounted on a long flexible cable connected to a control box. It is equipped with powerful LED lights, a high-resolution video camera, and a screen that allows the operator to see the inside surface of the well in real time.
How and who can benefit from well inspection cameras?
Well inspection cameras can be a valuable tool for various industries and applications. For example, they can be used by water utilities to inspect and maintain water wells or by oil and gas companies to inspect oil and gas wells.
In addition, environmental agencies use them to assess the condition of wells and underground tanks to ensure that they are not contaminating groundwater resources.
Finally, mining and drilling companies use well inspection cameras to monitor the progress of drilling operations and identify potential hazards or obstacles.
Such devices can help identify problems quickly and accurately and take appropriate action to correct them. This can prevent costly repairs, downtime, and ensure the safe and efficient operation of a well or underground structure.
In addition, environmental agencies use them to assess the condition of wells and underground tanks to ensure that they are not contaminating groundwater resources.
Finally, mining and drilling companies use well inspection cameras to monitor the progress of drilling operations and identify potential hazards or obstacles.
Such devices can help identify problems quickly and accurately and take appropriate action to correct them. This can prevent costly repairs, downtime, and ensure the safe and efficient operation of a well or underground structure.
What is the best downhole camera?
The best wellbore camera is the one that meets the specific requirements of the inspection task. Choosing the best device will depend on the particular needs and requirements of the user. Some factors to consider when choosing include cable length, video and image recording, display screen quality, and device durability and reliability.
What are the factors to consider when purchasing equipment to inspect wells?
While well inspection cameras can provide valuable information about the asset condition, some factors should be considered.
Cost: Typically, well cameras need general investment, especially for small-scale operations, which should be considered as part of the overall cost-benefit analysis of using this technology.
Limited access: If you're looking for a bigger system, access to an external power source is necessary. In some cases, additional equipment or techniques may be required to reach certain areas.
Size: the weight and bulkiness of the camera system can be a particular concern when inspecting wells, mines, or boreholes in remote or difficult-to-access locations. In these cases, it may be necessary to use specialized equipment for transportation.
Cost: Typically, well cameras need general investment, especially for small-scale operations, which should be considered as part of the overall cost-benefit analysis of using this technology.
Limited access: If you're looking for a bigger system, access to an external power source is necessary. In some cases, additional equipment or techniques may be required to reach certain areas.
Size: the weight and bulkiness of the camera system can be a particular concern when inspecting wells, mines, or boreholes in remote or difficult-to-access locations. In these cases, it may be necessary to use specialized equipment for transportation.
How much does it cost to rent well inspection cameras?
The cost of renting a well inspection camera can vary depending on the specific model and the length of the rental period. It is usually more cost-effective to purchase a well inspection camera rather than renting one if it will be used frequently. However, renting can be a good option for occasional or one-time use.
To find the best deal, leave a request or give us a call. We will find the best solution for your needs and budget.
To find the best deal, leave a request or give us a call. We will find the best solution for your needs and budget.
Are you looking for a ROBOTIC pipe camera machine?
Pipe Inspection Crawlers
• To Inspect Pipes Ranging from Ø4" to Ø120"
• Cable Length up to 4900 feet
• AC or Battery driven
• Industrial grade
• Cable Length up to 4900 feet
• AC or Battery driven
• Industrial grade
Downhole Well Video Inspection Solutions
Well inspection cameras are specialized cams to inspect the interior surface of water wells, boreholes, and other deep drilling projects. These devices are necessary to ensure the safety and integrity of drilling operations and monitor and maintain the wells themselves.
One of the key features of well inspection cameras is their ability to provide a high-quality 360-degree viewing angle. This allows for a comprehensive view of the well, including the walls, floor, and any obstacles that may be present. In addition, many well inspection cameras are equipped with adjustable lighting, allowing for clear, detailed images even in low-light conditions.
One of the key features of well inspection cameras is their ability to provide a high-quality 360-degree viewing angle. This allows for a comprehensive view of the well, including the walls, floor, and any obstacles that may be present. In addition, many well inspection cameras are equipped with adjustable lighting, allowing for clear, detailed images even in low-light conditions.
The camera head of such inspection systems is connected to a reinforced flexible cable (often up to 500 m) that can be lowered into a well or borehole and easily retrieved when the inspection is complete. The cameras come with a control unit with a built-in LCD and DVR. The control unit is powered by either a rechargeable battery or an external power source, allowing the cameras to work in remote areas or underground.
One of the latest models of well inspection cameras is the STRAHL HD portable well camera. This system's camera head has dual high-definition color cameras with powerful LED illumination on the side and bottom. It features waterproof housing, making it suitable for underwater inspections. In addition, the system comes with a DVR (digital video recorder) for storing recordings and a sensor for any necessary measurements.
One of the latest models of well inspection cameras is the STRAHL HD portable well camera. This system's camera head has dual high-definition color cameras with powerful LED illumination on the side and bottom. It features waterproof housing, making it suitable for underwater inspections. In addition, the system comes with a DVR (digital video recorder) for storing recordings and a sensor for any necessary measurements.
Downhole inspection cameras are used to inspect the condition of the well and the surrounding areas. These inspections are typically conducted at least once a year to ensure the well is in good condition and identify potential problems.
Well inspection cameras, such as the STRAHL PT well and duct camera and the STRAHL HD well camera, are essential tools for ensuring the safety and integrity of water wells, boreholes, and other deep drilling projects.
They provide detailed, high-quality images of the well's inner surface and can be used for both borehole inspections and wellbore surveys. The underwater inspection capability, powerful light source, and high-resolution LCD with DVR make the borehole camera a versatile and valuable addition to any inspection solution.
Well inspection cameras, such as the STRAHL PT well and duct camera and the STRAHL HD well camera, are essential tools for ensuring the safety and integrity of water wells, boreholes, and other deep drilling projects.
They provide detailed, high-quality images of the well's inner surface and can be used for both borehole inspections and wellbore surveys. The underwater inspection capability, powerful light source, and high-resolution LCD with DVR make the borehole camera a versatile and valuable addition to any inspection solution.
Pipe Camera vs Downhole Well Inspection Camera comparison. With an HD dual-camera head, 200 meters (656 ft) drop cable, and 13" monitor.
Advantages of water well inspection camera
There are several advantages to using well inspection cameras over more traditional survey methods.
-
Saves time and moneyOne major advantage is that these cameras allow you to examine the inside of a well or borehole in a non-invasive, safe and efficient way. This saves time and money because there is no need to physically penetrate the well or borehole or disturb the surrounding area. -
Recording and saving dataAnother advantage of well inspection cameras is the ability to capture high-resolution images and video. These cameras are equipped with high-quality lenses and sensors, allowing them to capture detailed images and video of the inside of the well. This will help identify any existing problems such as cracks, corrosion or debris. -
SafetyWell cameras are much safer than traditional pipe inspection methods because they eliminate the need for workers to penetrate the pipes physically. This reduces the risk of injury or accident and can improve overall safety at the job site.
Why Professionals Choose FIBERSCOPE Borehole Inspection Cameras
At FIBERSCOPE, we offer a wide range of well survey cameras to meet the needs of our customers. Our deep well inspection cameras are designed specifically for use in deep wells and boreholes and are designed for the harsh conditions often found underground. We also offer a range of downhole cameras that are designed for use in oil and gas wells and are equipped with high-quality sensors and lenses to produce clear and detailed video and images.
In addition to a wide range of equipment, we also offer a range of accessories and support services to ensure our customers have everything they need to get the most out of their cameras. This includes training and support from our team of experts, as well as repair and maintenance services to keep your equipment in top condition.
If you would like to learn more about the price or details of our borehole inspection cameras, please contact us. We'll be happy to answer any questions you may have and help you find the right equipment for your needs.
Send request In addition to a wide range of equipment, we also offer a range of accessories and support services to ensure our customers have everything they need to get the most out of their cameras. This includes training and support from our team of experts, as well as repair and maintenance services to keep your equipment in top condition.
If you would like to learn more about the price or details of our borehole inspection cameras, please contact us. We'll be happy to answer any questions you may have and help you find the right equipment for your needs.
