CCTV push camera VIPER MID is a cost-effective set designed to deliver high-quality inspections of sewers, building ducts/piping, wells, chimneys, and power plants
PUSH CAMERA VIPER MID
Price
Prices are for the basic camera package and are subject to change. To find out the exact price of the set, write or call us.
Monitor
+ Full Specifications
9" Color LCD monitor with Video output, file playback
Monitor Picture Resolution: 800x480 pixels
SD memory card slot
USB memory stick slot
Recording format - AVI / JPEG (720x576 pixels)
Power adaptor: 110~240VAC, 12VDC/1800mA
Rechargeable battery for portable use up to 3.5 hours
Li-ion battery box (4400mAh)
System Operating Temperature: -20°to 120°F
Operating temperature - 20°F~ 120°F (- 28C°~ 50°C)
Monitor Picture Resolution: 800x480 pixels
SD memory card slot
USB memory stick slot
Recording format - AVI / JPEG (720x576 pixels)
Power adaptor: 110~240VAC, 12VDC/1800mA
Rechargeable battery for portable use up to 3.5 hours
Li-ion battery box (4400mAh)
System Operating Temperature: -20°to 120°F
Operating temperature - 20°F~ 120°F (- 28C°~ 50°C)
Interchangeable Camera Heads
Ø 17mm (0.67") Mini Camera Head
- Interchangeable
- No sonde
- Straight view
- 6 built-in LED lights
- Waterproof IP67
Ø 23mm (1.0") Standard Camera Head
- Interchangeable
- 512Hz sonde available
- Straight view or Self-levelling
- 12 built-in LED lights
- Waterproof IP68
+ Full Specifications
Camera Head Diameter: 17mm (0.67"), 23mm (1.0") Straight-view, Side-view, or Self-levelling
Hi-resolution Color 1/4" image sensor with Sapphire glass lens
90/120° Field of View (FOV)
IP68 Waterproof
Illumination: white adjustable LEDs
Two protective/centering skids
Hi-resolution Color 1/4" image sensor with Sapphire glass lens
90/120° Field of View (FOV)
IP68 Waterproof
Illumination: white adjustable LEDs
Two protective/centering skids
Mid Cable Reel
- Working length up to 196 ft.
- Compatible with all VIPER's cameras
- Built-in footage counter
- Fiberglass push cable, Ø 6.5mm
- Waterproof, IP68
+ Full Specifications
Working lengths :
- 131' (40m) and 196' (60m)
What in the box
Control unit with monitor
Screwdriver
SD card
Card reader
Connection cables
Two centring skids
Power adapter 12V
Selected pushrod on the reel
The camera head
Spare O-rings
Mic
Keyboard
Write us about your application
and we will recommend the right tool to do the job without spending a fortune!
and we will recommend the right tool to do the job without spending a fortune!
Questions and Answers
Antoine they came in 4.9 ft or 9.8 ft, it's a 4-pin cable. The price for replacement is $70. please contact our sales team to proceed.
+1-800-239-9934
+1-800-239-9934
This camera can be submerged into water for up to 3 ft. So humid air is not a problem. No, this camera does not have any chemical resistance rating, it was designed for use on plumbing and sewer applications. No, this camera will not have enough light to illuminate 12" or 40" pipes. You may look at a different option - we have an Anaconda Sewer camera with a Pan-and-tilt head, Magnum and Trogloprobe camera systems as well as a few pipe crawler models.
One of your sales rep will send you a quote and a brochure for this camera shortly.
204-800-7856
One of your sales rep will send you a quote and a brochure for this camera shortly.
204-800-7856
Yes, we can make custom a Viper push camera much longer but due to force of friction you will not be able to push it through a pipe, it will start snaking in there.
The longer you need to go with your push camera, the stiffer the pushrod should be. Usually, the maximum length with push cameras is 400 ft.
The longer you need to go with your push camera, the stiffer the pushrod should be. Usually, the maximum length with push cameras is 400 ft.
The shipping costs are dependent on the size of the package being shipped and where it is being shipped to; please contact a Customer Service rep to get a quote for the price to ship to your location.
Our Viper Push Camera would be an adequate solution. Its head is slightly less than 1 inch (after you remove the protector off the camera head). It is able to take one 90 degrees turn in 2" pipe, but not multiple turns. We'd suggest you to look into more maneuverable inspection systems: Magnum Drain Scope and MiniFlex plumbing cameras.
Hi Michael, this camera comes with a 1-year manufacturer's warranty. It covers any defects you may come across
Do you have any questions?
Multimedia
How To Set Up the VIPER-ADV Inspection Camera Push Cable
Clogged Weeping Tile Inspection: VIPER Push Camera (PushCam 4)
Pipe Camera VIPER On-site footage from Colombia
Inspecting a Sewer Pipe with a Viper Drain Camera
Quick Guide to Viper Drain Camera
Toilet Inspection with a Viper Drain Camera
Image Capture Sample: Clogged Weeping Tile
Image Capture Sample: Weeping Tile to Clay Pipe Connection
Image Capture Sample: Weeping Tile
Reviews
Essential accessories
Content Oriented Web
Make great presentations, longreads, and landing pages, as well as photo stories, blogs, lookbooks, and all other kinds of content oriented projects.
Content Oriented Web
Make great presentations, longreads, and landing pages, as well as photo stories, blogs, lookbooks, and all other kinds of content oriented projects.
The System Full Description
The VIPER MID portable CCTV push camera is a cost-effective set designed to deliver high-quality inspections of sewers, building ducts/piping, wells, chimneys, and power plants. These sets feature small portable handheld probes coiled on a steel reel, with all of the accessories stored in one durable hard plastic carrying case, which takes up very little space and can easily travel to different job sites.
The VIPER MID push cameras have three main parts; the camera head, the push cable on the reel, and the monitor set up in the carrying case. The camera head houses a high-resolution camera chip with a wide-angle lens, designed to capture bright and crisp images and video of your inspections. There are also adjustable LED lights to illuminate the inspection area, a flexible spring to navigate corners, and a scratch-resistant sapphire lens. The PVC-coated fiberglass push cable is 6.5mm diameter, waterproof, and available in either 131.2' (40m) or 196' (60m) lengths built onto a steel reel. The waterproof plastic carrying case houses a 9' LCD screen and additional controls, including the DVR box, to capture images and uncompressed video directly to an SD memory card or an external USB storage, a rechargeable battery for portable use, a microphone, and a couple of skids for the camera head.
The VIPER MID push camera is the optimal solution when portability and maneuverability are extremely important. For this push camera set, four additional interchangeable camera heads are available for different applications. These include 1" or 0.67" diameter straight view, 1" diameter side view, and 1" diameter self-levelling camera head.
The 1" diameter self-levelling camera head comes with a built-in 512Hz frequency sonde. This allows the operator to locate the camera head underground or behind walls and to determine its exact depth up to 8 feet (2.5 m), depending on the strength of the signal and the pipe material. This is done using the Snaptrack Locator or any locator that picks up a 512Hz signal.
The 0.67" camera head is more maneuverable for quick and efficient inspections of drain pipes, small ducts, boiler pipes, and straight run lines with diameters less than 1.5". This head is great for hard-to-reach, tight inspection areas, as it will make a 90-degree bend in a 1.5" PVC pipe.
The VIPER MID push cameras have three main parts; the camera head, the push cable on the reel, and the monitor set up in the carrying case. The camera head houses a high-resolution camera chip with a wide-angle lens, designed to capture bright and crisp images and video of your inspections. There are also adjustable LED lights to illuminate the inspection area, a flexible spring to navigate corners, and a scratch-resistant sapphire lens. The PVC-coated fiberglass push cable is 6.5mm diameter, waterproof, and available in either 131.2' (40m) or 196' (60m) lengths built onto a steel reel. The waterproof plastic carrying case houses a 9' LCD screen and additional controls, including the DVR box, to capture images and uncompressed video directly to an SD memory card or an external USB storage, a rechargeable battery for portable use, a microphone, and a couple of skids for the camera head.
The VIPER MID push camera is the optimal solution when portability and maneuverability are extremely important. For this push camera set, four additional interchangeable camera heads are available for different applications. These include 1" or 0.67" diameter straight view, 1" diameter side view, and 1" diameter self-levelling camera head.
The 1" diameter self-levelling camera head comes with a built-in 512Hz frequency sonde. This allows the operator to locate the camera head underground or behind walls and to determine its exact depth up to 8 feet (2.5 m), depending on the strength of the signal and the pipe material. This is done using the Snaptrack Locator or any locator that picks up a 512Hz signal.
The 0.67" camera head is more maneuverable for quick and efficient inspections of drain pipes, small ducts, boiler pipes, and straight run lines with diameters less than 1.5". This head is great for hard-to-reach, tight inspection areas, as it will make a 90-degree bend in a 1.5" PVC pipe.
