Chimney inspection video cameras
Chimney inspection cameras (for chimney, fire places, ducts)
Sign Up for Updates
Welcome to our Chimney Inspection Cameras section. Chimney Inspection Cameras are becoming increasingly popular, especially when physical inspection of chimney surfaces is not feasible. This is particularly necessary for small diameter chimney liners, old stone flues in unknown condition, in order to get safety certificates, etc. Chimney and fireplace systems needs video CCTV inspections as much as other ducts or canals in the buildings. This done with using inspection video cameras with led light and long insertion shaft. Inspection cameras that MEDIT offers covers all kind of applications required to do high quality video inspection of chimney ducts.
These cameras represented by the two main classes.
- Economy video inspection chimney cameras with length of shaft up to 30 meters with forward view.
- Long shaft chimney video inspection cameras with length up to 70 meters.
- Rotating, pan and tilt cameras that can look on various directions and inspection different angles of vew.
Often cameras that is used to inspection chimney and fireplace ducts are called with various of terms: masonry chimney camera, chimney liners camera, chimney cctv system, chimney duct cameras, flue liner camera, air duct inspection system, air duct cameras, Chimney Camera, fireplace inspection camera.
- Portability
- Video recording
- rigid and flexible probes available
- Adjusable LCD angle (0 to 90)
CCTV cameras are successfully used for a number of applications including:
- • Checking the condition of chimney and flues liners • Chimney Surveying and documentation
- • Confirmation of suspected crack or other potential flaws in the components
- • Visual inspection of chimneys prior to lining
- • Checking for damages after chimney fire or any sudden disaster that could damage the chimney.
- • Video documentation for insurance claims
- • Inspections of any blockages, etc.
Medit Inc. develops and sells a wide spectrum of professional devices that ensure a quality and detailed inspection of chimney liners and air ducts. Here you will be able to find a product that suits your needs best depending on your requirements and budget. Our products will be indispensable while conducting Level 1 and Level 2 inspections. All our cameras not only serve for real time inspection, they also take snapshots and record video. You can choose a model that is right for you, from a wide angle direct view camera to a more sophisticated pan and tilt model for additional advantages during your inspection. Some cameras are designed to inspect the duct from below while others require roof access and need to be pushed down. We vouch for the reliability of our products and offer a 1 year worldwide warranty on them. Call our sales specialists today. They will be happy to answer all your questions or assist you to make a purchase.
- Length from 3 to 80 meters
- Water and Dust Proof
- view nowStarting at$5,999.00
Self-Leveling Pipeline Camera "Python"- Ø 52mm (2”) self leveling camera head
- Pipeline camera Working Length – 120 meter (394’)
- Sharp CCD chip with sapphire glass lens
- Built-in digital recorder
- 7” TFT LCD Display in a waterproof case
- Image / Video (AVI) files capture
- Video output to a TV monitor
- SD card slot to transfer captured files to a PC
- 30 Ultra Bright LED lights
Insertion Probe
• Length: 120 meter (394’) long flexible probe
• Diameter: 52mm (2”)
• Self leveling camera unit, with Sapphire lens
• No articulation
• Fiberglass cable
• 60° Field of View (FOV)
• 0° Direction of view (DOV)
• Waterproof design for portable use
• 30 LED lights to illuminate the inspection area
Image Hub
• 7” Color LCD monitor with Video output, file playback
• Monitor Picture Resolution: 320 (TV Lines)
• USB port to capture video to a hard drive
• Recording format - AVI
• Power adaptor: 110~240VAC, 12VDC/1800mA
• Rechargeable battery for portable use up to 3.5 hours
• Li-ion battery box (4400mAh)
• System Operating Temperature: -20°to 120°F
• Operating temperature - 20°F~ 120°F (- 28C°~ 50°C)1-877-613-2210 - view nowStarting at$1,190.00
Push Camera "Viper"- Ø 38mm (1.5”) detachable camera head
- Working Length – 20 meter(65.6'), 35 meter (114.9 foot) and 40 meter(131.2')
- CCD camera with sapphire glass lens
- Built-in digital video recorder
- 7” TFT LCD Display in a waterproof case
- Image (JPEG )/Video (AVI) file capture
- Video output to a TV monitor
- Files capture onto a SD memory card
- 8 super white LED lights
Insertion Probe
• Length: 20 meter(65.6'), 35 meter (114.9 foot) and 40 meter(131.2')
• Diameter: 36mm (1.4")
• Color CCD camera with sapphire glass lens
• No articulation
• Fiberglass cable
• 60° Field of View (FOV)
• 0° Direction of view (DOV)
• Waterproof design for portable use
• Illumination: 8 white LEDs
• Special gold point touch connector to camera
Image Hub
• 7” Color LCD monitor with Video output, file playback
• Monitor Picture Resolution: 320 (TV Lines)
• SD memory card slot
• Recording format - AVI
• IR remote control
• Power adaptor: 110~240VAC, 12VDC/1800mA
• Rechargeable battery for portable use up to 3.5 hours
• Li-ion battery box (4400mAh)
• System Operating Temperature: -20°to 120°F
• Operating temperature - 20°F~ 120°F (- 28C°~ 50°C)1-877-613-2210 - view nowStarting at$7,490.00
Anaconda-CH Pan-and-Tilt Chimney Inspection Camera- Pan and tilt advance chimney video inspection camera
- Pans 360⁰ and tilts 180⁰ to view and capture maximum details.
- Working Length up to 30 meters (98.4ft)
- 14 Super Bright LEDs
- 6.5” color TFT monitor
- Image and Video capture
- Compact (53mm), waterproof and dustproof camera head
- Camera centering skid
- Easy to carry, easy to operate
Camera.
CCD Type: SONY CCD
Horizontal resolution: 480TVL
Diameter of the camera head: 53mm (2.08in)
Pan &Tilt: Pan: 360degrees; Tilt: 180degrees
Auto level: Auto
Focus: Manual
Optical system 2.8mm (0.11in)
LED Lights
LED Lights: 14 LEDS
Brightness of the LEDS: Controllable
Display & Storage system
Size of the screen: 6.5’’ TFT Monitor
Brightness: 500cd/m2
Resolution: 640*480
Video format: MPEG4/AVI
Picture format: MPEG
Memory card: 4G(optional to 8G)
USB interface: USB output
Soft Cable Length: 10-30m (32.8 -98.4ft) (optional)
Bracket: Centering. To make sure the camera is in the center of the chimney
Power supply
Battery: DC12V 13000mah
Working time: Standby(LED off): 12hours;
In operation(LED on): 4hours1-877-613-2210
