Built for the toughest and hard to access environments, the TRACER T3 Tracked All-Terrain Crawler redefines what a pipe crawler can do. Unlike conventional CCTV inspection robots, this heavy-duty system powers through silt, standing water, steep slopes, deep trenches, and continuous bends with ease — making it the go-to solution for municipal drainage pipelines, box culverts, covered channels, and rivers. Its front and rear swing arms enable multiple posture adjustments on the fly, while dual motors push the crawler across surfaces that would stop other systems in their tracks. With optional add-ons including a 3D laser scanner and panoramic camera, the T3 goes beyond simple video footage — giving inspection teams the complete picture they need to diagnose problems accurately and act fast.
TRACER T3 Tracked
All-Terrain Pipe Robot
Overview
Price
Prices are for the basic pipe crawler package and are customizable. To find out the exact price of the set, write or call us.
Available Camera Heads
More products
+ Full Specifications
Pan-and-Tilt Camera Head
- Lens Movement: Electric rotation, continuous 360° radial, tilt 2 * 90°; one-click return to home
- Focus & Zoom: Auto focus, manual focus, 10x optical zoom
- Imaging System: Color 1/2.8” CMOS, 2 Megapixels, viewing angle 7°-81°, sensitivity 0.05Lux
- Lighting: 12x 1W flood LEDs, intensity continuously adjustable
- Viewpoint Indication: Clock reference method indicates current inspection object direction
- Impact Protection: Equipped with lens guard bar; sapphire glass lens, scratch/impact resistant
- Dimensions: 171mm * 105mm * 76mm
- Protection Rating: IP68, submersible up to 10 meters; built-in pressure sensor with indicator
- Operating Temperature: -10°C ~ 55°C
- Weight: 1.9kg
3D Laser
- Frequency: 200 Hz
- Distance Random Error: 1σ (@20m) < 2cm
- Angle Random Error: 1σ < 0.05°.Beam Divergence Angle: Horizontal 0.03°, Vertical 0.28°
- Near Blind Zone: < 1m
- Distance Accuracy: 2cm at 20m target distance, 80% reflectivity
- Weight: 500g
- Lens Movement: Electric rotation, continuous 360° radial, tilt 2 * 90°; one-click return to home
- Focus & Zoom: Auto focus, manual focus, 10x optical zoom
- Imaging System: Color 1/2.8” CMOS, 2 Megapixels, viewing angle 7°-81°, sensitivity 0.05Lux
- Lighting: 12x 1W flood LEDs, intensity continuously adjustable
- Viewpoint Indication: Clock reference method indicates current inspection object direction
- Impact Protection: Equipped with lens guard bar; sapphire glass lens, scratch/impact resistant
- Dimensions: 171mm * 105mm * 76mm
- Protection Rating: IP68, submersible up to 10 meters; built-in pressure sensor with indicator
- Operating Temperature: -10°C ~ 55°C
- Weight: 1.9kg
3D Laser
- Frequency: 200 Hz
- Distance Random Error: 1σ (@20m) < 2cm
- Angle Random Error: 1σ < 0.05°.Beam Divergence Angle: Horizontal 0.03°, Vertical 0.28°
- Near Blind Zone: < 1m
- Distance Accuracy: 2cm at 20m target distance, 80% reflectivity
- Weight: 500g
Cable Reel with Control System
- Tablet to Control and Operate the Crawler
- On Screen Footage Counter, Inclinometer, with Pressure Sensors
- Motorized Drum with 984ft. (300m) of Kevlar Reinforced Cable
+ Full Specifications
Control Tablet
- Configuration: Tablet-based, with built-in acquisition and analysis software; Parameters such as CPU, Memory, Storage Capacity, Screen Size, etc., can be customized.
- Control Functions: Controls crawler movement, front/rear swing arm up/down, lifting frame up/down, lens rotation, cable reel winding, light source adjustment, etc
- Video Display: Can display front and rear video simultaneously with adjustable resolution
- Status Display: Displays real-time information such as time, date, travel distance, and crawler attitude
- Text Input: Supports text input for overlay display on the video feed.
- Auxiliary Functions: Automatically identifies crawler model, calculates adapted pipe diameter, and displays real-time lens height from ground.
- Clock Reference: Provides clock positioning for the current defect location and displays it.
- Alarm Functions: Includes roll angle over-limit alarm to prevent overturning; includes high and low air pressure alarms.
- Interactive Buttons: One-click startup of analysis software for interpretation and report analysis.
Drum and Cable
- Cable Length: Standard cable length 300 meters.
- Cable Parameters: Coaxial cable, 500 kg Kevlar tensile strength, imported polyurethane sheath, cable diameter <9mm, waterproof, abrasion-resistant, acid/alkali resistant, corrosion-resistant.
- Winding: Software-controlled automatic winding and jog winding.
- Automatic Layering: Ensures orderly cable distribution on the drum during winding/unwinding.
- Counting: Uses a high-precision encoder with a resolution of 1mm.
- Interfaces: Wireless interface, Ethernet port.
- Protection Rating: IP65, dust-tight, protected against water jets.
- Dimensions: 670mm * 590mm * 637mm.
- Weight: 104kg (including 300 meters of cable).
- Configuration: Tablet-based, with built-in acquisition and analysis software; Parameters such as CPU, Memory, Storage Capacity, Screen Size, etc., can be customized.
- Control Functions: Controls crawler movement, front/rear swing arm up/down, lifting frame up/down, lens rotation, cable reel winding, light source adjustment, etc
- Video Display: Can display front and rear video simultaneously with adjustable resolution
- Status Display: Displays real-time information such as time, date, travel distance, and crawler attitude
- Text Input: Supports text input for overlay display on the video feed.
- Auxiliary Functions: Automatically identifies crawler model, calculates adapted pipe diameter, and displays real-time lens height from ground.
- Clock Reference: Provides clock positioning for the current defect location and displays it.
- Alarm Functions: Includes roll angle over-limit alarm to prevent overturning; includes high and low air pressure alarms.
- Interactive Buttons: One-click startup of analysis software for interpretation and report analysis.
Drum and Cable
- Cable Length: Standard cable length 300 meters.
- Cable Parameters: Coaxial cable, 500 kg Kevlar tensile strength, imported polyurethane sheath, cable diameter <9mm, waterproof, abrasion-resistant, acid/alkali resistant, corrosion-resistant.
- Winding: Software-controlled automatic winding and jog winding.
- Automatic Layering: Ensures orderly cable distribution on the drum during winding/unwinding.
- Counting: Uses a high-precision encoder with a resolution of 1mm.
- Interfaces: Wireless interface, Ethernet port.
- Protection Rating: IP65, dust-tight, protected against water jets.
- Dimensions: 670mm * 590mm * 637mm.
- Weight: 104kg (including 300 meters of cable).
Tractor
- Minimum pipe diameter 400mm(16")
- IP68 submersible up to 10 metres
- Dual 400W motors, up to 18 m/min travel speed
- 300 mm obstacle crossing, 45° gradeability
- Independently detachable 84W LED lighting system
+ Full Specifications
- Applicable Pipe Diameter/Box Culvert: 400mm - 20000mm.
- Applicable Pipelines: Combined sewer, domestic sewage, industrial wastewater, stormwater, water supply pipes, or box culverts.
- Lens Lifting: Electric lifting frame with a lift range up to 310mm.
- Main Drive: Dual 400W motors, track or wheel drive, maximum travel speed up to 18m/min.
- Swing Arm Lifting: Detachable, dual 90W DC motors, rotation angle ±120°, lift range up to 250mm (maximum swing arm axle height from ground: 250mm).
- Wheels: Equipped with 12-inch wheels.
- Gradeability: Maximum gradeability 45°, depending on pipe/culvert conditions.
- Obstacle Crossing Height: 300mm.
- Trench Crossing Width: 450mm.
- Circuit Protection: Automatic protection against motor stall, overcurrent, overvoltage.
- Lighting: Independently detachable. Forward: 28x LEDs, total 84W; Rear: 2x LEDs, total 6W; all light intensity continuously adjustable.
- Rearview Camera: For observing during retrieval and cable winding; resolution 1920x1080 (2MP).
- Sonde: Features pipeline locating functionality.
- Materials: Brass, nickel-plated, stainless steel, aluminum (anti-corrosion treated).
- Protection Rating: IP68, submersible up to 10 meters; built-in pressure sensor with indicator.
- Operating Temperature: -10°C ~ 55°C.
- Overall Dimensions: 1030 * 400mm * 300mm; Dimensions after removing swing arms: 755 * 260mm * 300mm; Wheeled configuration dimensions: 755 * 460mm * 350mm.
- Weight: 57kg.
- Applicable Pipelines: Combined sewer, domestic sewage, industrial wastewater, stormwater, water supply pipes, or box culverts.
- Lens Lifting: Electric lifting frame with a lift range up to 310mm.
- Main Drive: Dual 400W motors, track or wheel drive, maximum travel speed up to 18m/min.
- Swing Arm Lifting: Detachable, dual 90W DC motors, rotation angle ±120°, lift range up to 250mm (maximum swing arm axle height from ground: 250mm).
- Wheels: Equipped with 12-inch wheels.
- Gradeability: Maximum gradeability 45°, depending on pipe/culvert conditions.
- Obstacle Crossing Height: 300mm.
- Trench Crossing Width: 450mm.
- Circuit Protection: Automatic protection against motor stall, overcurrent, overvoltage.
- Lighting: Independently detachable. Forward: 28x LEDs, total 84W; Rear: 2x LEDs, total 6W; all light intensity continuously adjustable.
- Rearview Camera: For observing during retrieval and cable winding; resolution 1920x1080 (2MP).
- Sonde: Features pipeline locating functionality.
- Materials: Brass, nickel-plated, stainless steel, aluminum (anti-corrosion treated).
- Protection Rating: IP68, submersible up to 10 meters; built-in pressure sensor with indicator.
- Operating Temperature: -10°C ~ 55°C.
- Overall Dimensions: 1030 * 400mm * 300mm; Dimensions after removing swing arms: 755 * 260mm * 300mm; Wheeled configuration dimensions: 755 * 460mm * 350mm.
- Weight: 57kg.
Tell us about your application and we will recommend you the right tool to do the job!
The System Full Description
Introducing the next generation of heavy-duty inspection with the new TRACER T3 Tracked All-Terrain Pipe Robot. This system is engineered to operate in the most challenging environments, capable of inspecting pipelines, box culverts, and covered channels from DN400mm (15.7") all the way up to 20,000mm (787"). Its unique adaptive posture control allows a single operator to traverse deep silt, standing water, steep slopes, and high ledges where conventional crawlers cannot function, making it the definitive solution for tough municipal and industrial inspections. The crawler itself is fully protected to IP68 standards, allowing it to be submerged up to 10 meters, while the electric cable reel is rated IP65 for protection against dust and water. The system is powered by a robust 300-meter, Kevlar-reinforced coaxial cable with a 500 kg tensile strength and a durable polyurethane sheath. Safety is paramount, with automatic circuit protection against motor stalls and overcurrents, plus integrated sensors that provide alarms for roll angle and internal pressure.
The crawler features a powerful dual-motor drive system (800W total) and a revolutionary multi-terrain track structure with detachable front and rear swing arms. These arms provide a ±120° rotation and 250mm of lift, while a separate electric lifting frame raises the camera an additional 310mm. The primary Pan-Tilt-Zoom (PTZ) camera head offers continuous 360° rotation, 10x optical zoom, and a high-sensitivity 2MP CMOS sensor. For illumination, 28 high-intensity forward LEDs (84W total) flood the inspection area with light, supplemented by a 2MP rearview camera for observing cable and retrieval.
The electric cable reel and control system provide automated operation. The reel features software-controlled automatic winding and layering to ensure orderly cable management, while a high-precision counter tracks distance with 1mm resolution. The entire system is managed from a ruggedized, tablet-based control terminal that can display front and rear video feeds simultaneously. The control software allows for text overlay, displays real-time crawler attitude and distance, and supports one-click integration with analysis and reporting software.
The Tracer T3 system includes the tracked crawler, electric cable reel with 300m of cable, and the tablet-based main controller. The system is fully compatible with the included PipeScan (for Android-based field inspection) and PipeVision (for desktop-based video interpretation and reporting) software suites, which support AI-powered defect interpretation and generate detailed reports compliant with CJJ181.
Optional features include a high-precision 3D laser scanner that enables the robot to collect 3D point cloud data and construct detailed 3D models of the culvert. This allows for precise measurement of defects, tracing of drainage outlets, and investigation of structural issues.
The crawler features a powerful dual-motor drive system (800W total) and a revolutionary multi-terrain track structure with detachable front and rear swing arms. These arms provide a ±120° rotation and 250mm of lift, while a separate electric lifting frame raises the camera an additional 310mm. The primary Pan-Tilt-Zoom (PTZ) camera head offers continuous 360° rotation, 10x optical zoom, and a high-sensitivity 2MP CMOS sensor. For illumination, 28 high-intensity forward LEDs (84W total) flood the inspection area with light, supplemented by a 2MP rearview camera for observing cable and retrieval.
The electric cable reel and control system provide automated operation. The reel features software-controlled automatic winding and layering to ensure orderly cable management, while a high-precision counter tracks distance with 1mm resolution. The entire system is managed from a ruggedized, tablet-based control terminal that can display front and rear video feeds simultaneously. The control software allows for text overlay, displays real-time crawler attitude and distance, and supports one-click integration with analysis and reporting software.
The Tracer T3 system includes the tracked crawler, electric cable reel with 300m of cable, and the tablet-based main controller. The system is fully compatible with the included PipeScan (for Android-based field inspection) and PipeVision (for desktop-based video interpretation and reporting) software suites, which support AI-powered defect interpretation and generate detailed reports compliant with CJJ181.
Optional features include a high-precision 3D laser scanner that enables the robot to collect 3D point cloud data and construct detailed 3D models of the culvert. This allows for precise measurement of defects, tracing of drainage outlets, and investigation of structural issues.
