A highly portable Full HD pipe inspection crawler for municipal sewer mains, storm drains, and larger industrial pipes. Optical zoom, a powered camera lift, and groundwater inflow detection come together on a single modular platform.
- 10× Optical zoom + Powered camera lift
- Groundwater inflow detection included
- Optional Laser diameter and ovality measurement
- Optional Laser measurement of cracks and objects
- Two-battery power with your specified interface
STORMER X Municipal Grade
Pipe Crawler
- PIPE RANGE6″ to 40″to 80″ with AUX lighting
- CAMERA10x Optical+ 12x digital, Full HD
- GROUNDWATERInflow Sensorincluded as default
- LATERALLaunch-readyadd the module
What is STORMER X?
STORMER X is a portable, battery-powered CCTV pipe crawler for 6″ to 40″ (DN150–1000) sewer, storm, and culvert inspection, extendable to 80″ (DN2000) with additional lighting.
It combines a steerable crawler and electric camera lift with a Full HD pan-and-tilt camera with 10x optical zoom, precise laser measurement, a groundwater inflow sensor included at no charge, and a self-straightening cable reel. It is made in the EU for North America and sold and supported by FIBERSCOPE.
It combines a steerable crawler and electric camera lift with a Full HD pan-and-tilt camera with 10x optical zoom, precise laser measurement, a groundwater inflow sensor included at no charge, and a self-straightening cable reel. It is made in the EU for North America and sold and supported by FIBERSCOPE.
Sets and Pricing
Two sets. Both start with the full platform.
STORMER X Base Set
Best for mainline and culvert condition assessment, where video and groundwater inflow are the priority. |
What’s included
- Full HD pan & tilt camera head, 10x optical / 12x digital zoom
- Steerable crawler with speed and direction control
- Electric camera lift
- Groundwater inflow sensor, included free
- Inclination measurement and automatic anti-tipping
- Rear-view camera
- Extension wheels for 6″, 12″ and 16″ pipe
- Lifting hook
- Motorized reel with automatic cable straightening
- 656 ft (200 m) non-coaxial cable
- Manhole cable-protection roller
- Rugged control tablet with joysticks
- IKAM Inspection software, lifetime license
from $69,900
STORMER X Advanced Set
Best for rehabilitation design, contract inspection, and any job that ends in a measured report. |
What’s included
- Full HD pan & tilt camera head, 10x optical / 12x digital zoom
- Laser for diameter and ovality measurement
- Laser for crack and object width
- Steerable crawler with speed and direction control
- Electric camera lift
- Groundwater inflow sensor, included free
- Inclination measurement and automatic anti-tipping
- Rear-view camera
- Extension wheels for 6″, 8", 12″ and 16″ pipe
- Lifting hook
- Motorized reel with automatic cable straightening
- Manhole cable-protection roller
- 984 ft (300 m) cable in place of 656 ft
- Rugged control tablet with joysticks
- IKAM Inspection software, lifetime license
- 512 Hz locating transmitter
from $79,700
Starting prices in USD. Batteries, freight, and taxes are extra. Your written quote confirms configuration, lead time, and delivered price.
Built for crews that inspect without a CCTV truck
- Groundwater Inflow DetectionAll STORMER X crawlers are fitted with a sensor for detecting groundwater entering the pipe, and the software that allows an infiltration study to identify particular joints and sections.1
- Runs on Batteries You UseThe reel accepts two batteries from mainstream tool brands you select, such as DeWalt or Milwaukee. When installing the system in a van or truck, it should be operated using 110–240 V AC.2
- Rolls to ManholesThe reel, crawler and tablet are combined into a single wheeled unit. The system can be positioned in ditches, parking structures, and on plant floors before being loaded back into the pickup.3
- Up to 1,650 ft of Working LengthStandard sets come with 656 feet (Base) or 984 feet (Advanced) of non-coaxial cable; if your manhole spacing or culvert runs require more, we will quote the reel up to 1,650 feet.4
- Configured to Your ApplicationEach STORMER pipe crawler is custom-built. Let us know your requirements, and we will match the wheel kits, camera options, cable length, and portable cart or van to your needs.5
- WiFi Remote TroubleshootingWith your permission, a qualified technician can connect to the system's control electronics over the internet to run diagnostics and guide you through the necessary repair.6
- Made in EU for North AmericaSTORMER is designed and manufactured by Zikmund Electromics, a company with over 35 years of industry experience. The system has been adapted for the North American customers.7
- North American SupportQuotes, warranty claims, parts, and service all run through FIBERSCOPE, serving the US and Canada on Central Time. You deal with the North American company from the first call to repair.8
- Modular and Cross-compatibleIt uses the same reel, tablet, software, and power as the STORMER S, so a mixed fleet can operate on a single set of spares and a single workflow. The lateral lunch add-on is available upon request.9
- Center the camera in big pipe and zoom into a hairline crackThe electric lift moves the camera head towards the centre line of the pipe, enabling the large-diameter pipe to be viewed directly end-on with even lighting. The Full HD camera head is equipped with panning and tilting facilities, 10x optical and 12x digital zoom, autofocus, and 2,160-lumen LED lighting.
The Advanced set includes lasers for measuring diameter, ovality, and the width of cracks and objects displayed on screen.- Full HD 1920 × 1080 at 60 fps
- 10x optical + 12x digital zoom, autofocus
- 2,160-lumen LED lighting, 0.1 lux sensitivity
- Electric camera lift
- Lasers for diameter, ovality and crack width (Advanced set)
- Optional lighting kit for pipe over 80″
- Two tool batteries power the whole systemThe battery adapter for the reel uses two batteries from a brand your team might already keep on hand, for example, DeWalt or Milwaukee; you thus avoid the need for proprietary batteries and the cost of replacing them, and charging is carried out on the rack you already have.
When using a dedicated truck or van, you should use the 110–240 V, 50/60 Hz electrical adapter. The reel can be connected to the tablet via Wi-Fi or LAN, and it also connects to an optional control unit for van installations.- Battery adapter for DeWalt, Milwaukee and other major brands
- 110–240 V, 50/60 Hz AC adapter for van or truck installs
- Wi-Fi, LAN or control-unit connection
- Large wheels and grab bars for one-person moves
- A reel that lays cable straight and holds the crawler on a gradeThe cable is automatically straightened as it is wound, whether you're using the power or winding it by hand. With a one-way brake, you can adjust the resistance when moving forward and the cable runs without any resistance when going in reverse.
The distance sensor is used to record the footage for the report. There is an emergency stop positioned on the reel, and the remote control panel can be removed so that you are able to operate the reel from where you are standing.- Automatic cable straightening, motorized and manual
- Adjustable one-way brake
- Distance sensor for footage
- Emergency stop
- Removable rear control panel
- Non-coaxial cable that resists breakage
- Code, measure and report from the same tabletEach STORMER pipe crawler comes with a lifetime license for its inspection software, which codes defects in accordance with EN 13508-2, plots the inclination along the length of the pipe, calculates the ovality, and can print either single or batch reports. Results can be exported to GIS in ISYBAU XML format, and a free viewer is available, allowing engineers and clients to open the reports without a license.
The rugged control tablet has physical joysticks and a sunlight-readable screen, and it connects to the reel via Wi-Fi or a cable. Another person can connect and watch the inspection live.
State in your quote request that your agency or contract requires NASSCO PACP coding, and we'll confirm the reporting workflow before you place an order.
Find infiltration while the crawler is still in the pipe
STORMER X detects groundwater entering the pipe as it drives and records the readings with the inspection. The software charts inflow against distance, so your report shows which joints and segments take on water, with the video to back it up.
Add lateral launch to the crawler you already own
The lateral launch module mounts on the STORMER X pipe crawler and works with its reel, so the system you bought for mainline inspection can enter service laterals from the main. It handles mains from 10″ to 48″ and laterals from 4″ to 12″.
STORMER X
Crawler + 10x zoom camera on electric lift + groundwater sensor
To Inspect 6″ to 80″ Pipes
To Inspect 6″ to 80″ Pipes
STORMER Lateral Launch Module
Mounts on the STORMER X crawler. Uses the Zikmund push camera with a launching guide.
Mains 10″–48″, laterals 4″–12″
Mains 10″–48″, laterals 4″–12″
Applications
Where STORMER X earns its keep
Trunk sewers and interceptors
Condition assessment of 18″ to 80″ mains, with the camera centered on the electric lift.
Storm mains and road culverts
Inspect culverts and outfalls up to 80″ with the added AUX lighting kit.
Inflow and infiltration studies
Locate where groundwater enters the system, joint by joint, with the included sensor.
Rehabilitation design and QA
Measure ovality and crack widths before lining and verify the result after
Lateral inspection from the main
Add the lateral module to inspect 4″ to 12″ services without excavation.
Industrial and utility pipe
Large process drains, cooling-water lines and stormwater systems at plants and facilities.
STORMER X Technical Specifications
STORMER S or STORMER X? Key deferences
Most of your work in 4″ to 16″ collection lines? See the STORMER S Pipe Robot
Questions and Answers
The lead time is around 6-8 weeks + shipping time. Depends on configuration.
STORMER X inspects pipe from 6″ to 40″ in diameter (DN150–1000), and up to 80″ (DN2000) with the additional lighting kit. The electric camera lift centers the view in larger pipe.
The basic setup consists of the tractor with a camera head, a winch with cable, and rugged control tablet with integrated software.
Yes, the pipe crawler is equipped with a 512Hz sonde beacon that allows the operator to detect the crawler once it is in the pipe.
STORMER X runs on two standard cordless tool batteries of your choice, such as DeWalt or Milwaukee, through a battery adapter on the reel. E.g., two batteries, minimum 9 Ah optimum 15 Ah, power up the unit. Batteries are not included, so you can use packs your crew already owns. For a van or truck install, a 110–240 V, 50/60 Hz AC adapter powers the system instead.
The sensor on the STORMER X crawler detects groundwater entering the pipe as the crawler drives and records it with the inspection. The software charts inflow against distance, so infiltration studies can point to specific joints and segments. It is included in both sets at no extra charge.
Yes. Both models share the same reel, cable, tablet, software and power system; only the crawler and camera differ. A fleet that runs both keeps one set of spares and one workflow, and an S owner can add the X crawler to the reel they already have.
