Experience Unmatched Precision with the iX3D Stereo Measurement Video Borescope, a revolutionary tool for 3D inspection and analysis in critical applications. Using dual “chip-in-the-tip” image sensors and advanced PXL+ 3D modeling software, the system turns live stereo images into accurate 3D data – right on a rugged industrial tablet.
Available with a 6 mm flexible probe in lengths from 1.5 m to 7.5 m, and with forward-viewing (0°) or side-viewing (90°) stereo optics, the iX3D is ideal for high-stakes remote visual inspection (RVI) in aerospace, power generation, oil & gas, automotive and general manufacturing.
Available with a 6 mm flexible probe in lengths from 1.5 m to 7.5 m, and with forward-viewing (0°) or side-viewing (90°) stereo optics, the iX3D is ideal for high-stakes remote visual inspection (RVI) in aerospace, power generation, oil & gas, automotive and general manufacturing.
iX 3D STEREO MEASUREMENT
VIDEO BORESCOPE
Overview
Price
Price is for the basic custom-built package and is subject to change. To determine the exact cost of the set, please get in touch with us by phone or email.
Why Choose the iX 3D Stereo Measurement Video Borescope?
- Superior 3D Measurement AccuracyAdvanced stereo vision with dual AIT image sensors to obtain precise measurements of defects, components, and surface features,
- Intuitive PXL+ SoftwareLicensed software offers real-time data processing, generates detailed 3D models, and colored depth maps for a comprehensive understanding of the inspected area.
- Rugged & Durable DesignBuilt to withstand the harshest industrial environments, the iX3D video borescope is shock-proof, waterproof, and resistant to oils and saline.
- Proven Brand CredibilityWith over 20 years of experience in the industrial inspection market, ITConcepts designs and builds some of the most reliable and trusted videoscopes available.
Control Unit
iX3D Pad
- 10.1" Sunlight Readable Outdoor Display with Digitizer Support
- Powerful Intel® Core™ i5-7300U Processor
- Windows® 10 Pro 64-bit Operating System
- Up to 11 hrs of Battery Life
- Robust Rugged Tablet PC for Industrial Use
- IP65, MIL-STD 461G, MIL-STD 810G Proofed, Corning® Gorilla® Glass Screen Protector
- Can be Operated with Gloves
+ Full Specifications
iX3D PAD (Tablet PC as monitor)
Processor: Intel® Core™ i5-7300U (2x 2.60 GHz up to 3.50 GHz with Intel® Turbo Boost Technology, HD 620, 3M cache)
Operating system: Windows® 10 Pro 64-bit
Optional operating system: Windows® 10 IoT
Display size: 10.1“ (25.65 cm)
Display Technology: Sunlight-readable outdoor display with digitizer support
Resolution: 1,920 x 1,200 pixels (WUXGA)
Brightness: 1,000 cd/m²
Screen protector: Corning® Gorilla® Glass
Touchscreen: Capacitive
Touch operation: Multi-touch
RAM (permanently soldered): 8 GB DDR3 SDRAM
Hard disk: 512 GB SSD M.2
WLAN: IEEE 802.11 a/b/g/n/ac
Interfaces: 1x USB 3.1 Type-A™, 1x USB 3.1 Type-C™ (1,5A), 1x microHDMI, 1x LAN (1Gbs), 1x serial (RS232), 2x RF Pass-through port (for WLAN, GNSS, WWAN), Docking port
Camera front: 2.0 megapixels
Rear camera: 8.0 megapixels
Military standard: MIL-STD 461G, MIL-STD 810G
Degree of protection: IP 65
Battery: 6-cell Li-ion battery, approx. 4,500 mAh (12-month guarantee)
Battery life: up to 11 hours
Power supply: 65 watts, external
Input: 100-240V AC /Output: 19V DC / 3.42A
Weight: 1,360g
Dimensions: (WxHxD): 280 x 195 x 23mm
Processor: Intel® Core™ i5-7300U (2x 2.60 GHz up to 3.50 GHz with Intel® Turbo Boost Technology, HD 620, 3M cache)
Operating system: Windows® 10 Pro 64-bit
Optional operating system: Windows® 10 IoT
Display size: 10.1“ (25.65 cm)
Display Technology: Sunlight-readable outdoor display with digitizer support
Resolution: 1,920 x 1,200 pixels (WUXGA)
Brightness: 1,000 cd/m²
Screen protector: Corning® Gorilla® Glass
Touchscreen: Capacitive
Touch operation: Multi-touch
RAM (permanently soldered): 8 GB DDR3 SDRAM
Hard disk: 512 GB SSD M.2
WLAN: IEEE 802.11 a/b/g/n/ac
Interfaces: 1x USB 3.1 Type-A™, 1x USB 3.1 Type-C™ (1,5A), 1x microHDMI, 1x LAN (1Gbs), 1x serial (RS232), 2x RF Pass-through port (for WLAN, GNSS, WWAN), Docking port
Camera front: 2.0 megapixels
Rear camera: 8.0 megapixels
Military standard: MIL-STD 461G, MIL-STD 810G
Degree of protection: IP 65
Battery: 6-cell Li-ion battery, approx. 4,500 mAh (12-month guarantee)
Battery life: up to 11 hours
Power supply: 65 watts, external
Input: 100-240V AC /Output: 19V DC / 3.42A
Weight: 1,360g
Dimensions: (WxHxD): 280 x 195 x 23mm
Measurement Software with PXL+™ Technology
Software Features
- Modern and Intuitive User Interface
- Professional High-Precision 2D and 3D Stereo Measurement
- 360° 3D View Along with Colored Depth Map
- Precise Management of the Measurement Points Set
- High Measurement Accuracy
- Images and Videos Can be Stored Directly in the Company Network Storage System
- Online Remote Access to Inspection and Measurement Data (Remote Software not Included)
+ Full Specifications
Measurement Software with PXL+™ Technology
Version: 1.3.0.1
Category: Endoscope 3D measurement software exclusively for endoscope iX3D of IT Concepts GmbH, Lahnau, Germany
Languages: English, German, Italian, Russian, Spanish
Requirements: Operating System Windows 10 | Measurement functionalities included in IX3D-Software have to be calibrated by manufacturer after/with installation of iX3D-Software
Intellectual Properties: 3D.aero GmbH, Billhorner Deich 96, D-20539 Hamburg, Germany (info@3d-aero.com)
Live camera: Current live view for visual inspection (not in measurement mode; for visual inspection purposes only)
File management: Set up of / naming of / moving up/down in file folder hierarchy (main and sub folders). Selection of files to be deleted, Selection of a folder in which new images should be stored automatically after image taking, Images/videos stored in the file manager are visible as thumbnails, Viewing single images in a larger frame, start/stop video in a larger frame.
Settings: Language preference (English, German, Italian, Russian, Spanish), Freeze live view after image taking, Set up of working folder/export folder location, file name (incl. date/time), Image/Video file name prefix/suffix, Image enhancement of sharpness, brightness, and contrast, Invert colors, Mirror image horizontal/vertical
Exposure mode: Exposure of the camera (automatic/manual setting)
Inspection mode: Measurement mode (off)
Inspection camera: Capture/save/delete images taken in inspection mode (2D)
Inspection video: Start/stop video captured in measurement mode (2D)
Measurement mode: Measurement mode (on), Stereo view of cameras (on = 2 images visible/off = 1 image visible)
Measurement camera: Capture/save/delete images taken in measurement mode (3D). The result of the measurement is visible right after image taking (red color for areas without a measurement result)
Measurement video: Start/stop video captured in measurement mode (3D)
Measurement methods: Point-to-point, Point-to-line, Point-to-plane (3D), Multipoint line, Colored 3D point cloud as a Depth map of measurement, 360° 3D view of the model in an image (3D; incl. different colors for each layer)
Measurement result: All values in Millimeter (mm), save/delete images with/after measurement results
Marker settings (available for images only): Support for reporting purposes (available in inspection & measurement mode): Include/save/delete circles, squares, lines, multipoint lines, arrows in saved images: Include/save/delete text information in saved images
Version: 1.3.0.1
Category: Endoscope 3D measurement software exclusively for endoscope iX3D of IT Concepts GmbH, Lahnau, Germany
Languages: English, German, Italian, Russian, Spanish
Requirements: Operating System Windows 10 | Measurement functionalities included in IX3D-Software have to be calibrated by manufacturer after/with installation of iX3D-Software
Intellectual Properties: 3D.aero GmbH, Billhorner Deich 96, D-20539 Hamburg, Germany (info@3d-aero.com)
Live camera: Current live view for visual inspection (not in measurement mode; for visual inspection purposes only)
File management: Set up of / naming of / moving up/down in file folder hierarchy (main and sub folders). Selection of files to be deleted, Selection of a folder in which new images should be stored automatically after image taking, Images/videos stored in the file manager are visible as thumbnails, Viewing single images in a larger frame, start/stop video in a larger frame.
Settings: Language preference (English, German, Italian, Russian, Spanish), Freeze live view after image taking, Set up of working folder/export folder location, file name (incl. date/time), Image/Video file name prefix/suffix, Image enhancement of sharpness, brightness, and contrast, Invert colors, Mirror image horizontal/vertical
Exposure mode: Exposure of the camera (automatic/manual setting)
Inspection mode: Measurement mode (off)
Inspection camera: Capture/save/delete images taken in inspection mode (2D)
Inspection video: Start/stop video captured in measurement mode (2D)
Measurement mode: Measurement mode (on), Stereo view of cameras (on = 2 images visible/off = 1 image visible)
Measurement camera: Capture/save/delete images taken in measurement mode (3D). The result of the measurement is visible right after image taking (red color for areas without a measurement result)
Measurement video: Start/stop video captured in measurement mode (3D)
Measurement methods: Point-to-point, Point-to-line, Point-to-plane (3D), Multipoint line, Colored 3D point cloud as a Depth map of measurement, 360° 3D view of the model in an image (3D; incl. different colors for each layer)
Measurement result: All values in Millimeter (mm), save/delete images with/after measurement results
Marker settings (available for images only): Support for reporting purposes (available in inspection & measurement mode): Include/save/delete circles, squares, lines, multipoint lines, arrows in saved images: Include/save/delete text information in saved images
Operating Handle and Insertion Probe
- 4mm and 6mm Insertion Probes with True Tactile Feel 4-way Tip Articulation
- The Enclosed High-Grade Tungsten Braided Sheath Design is Durable and Corrosion-Free.
- Cross-Compatible Probes with 0° or 90° Direction of View (DOV) for Stereo Cameras
- 4.9ft (1.5m) - 24.6ft (7.5m) Working Lengths
- Two AIT High-Resolution Image Sensor Chips Per Distal End
- High-Power LED Illumination on the Tip with 3-Step Control
- Truly Single-Handed Control Operations Probes
+ Full Specifications
Operating Handle and Insertion Probe
Tip operating temperature: 284°F (140°C) less than 5 Minutes / -13°F (-25°C) to 176°F (+80°C)
System operating temperature: -13°F (-25°C) to 115°F (+46°C)
Storage temperature: -13°F (-25°C) to 140°F (+60°C)
Relative humidity: 95% less than - non-condensing
Camera Sensor 0°: AIT Advanced Image Sensor
Camera Sensor 90°: AIT Advanced Image Sensor
Ergonomics: ± 90° rotatable display, alt. ±90° rotatable handle
Weight: 1.65Kg (+/- depending on probe diameter and working length)
Waterproof: Probe and distal End up to 1 bar- 10.2m H2O
Resistance: Probe and distal End to oils and saline (5%)
Probe diameter: 6.0mm or 4.0mm
Working length: 4.9ft (1.5m) - 24.6ft (7.5m)
Direction of view: 0° or 90°
Working distance: 10-50mm (6mm probe) or 4-20mm (4mm probe)
Articulation: 4-way
Resolution: 800x800px (6mm probe) or 400x400px (4mm probe)
Illumination Type: High-power LED on the TIP
Illumination control: 3 steps
Tip operating temperature: 284°F (140°C) less than 5 Minutes / -13°F (-25°C) to 176°F (+80°C)
System operating temperature: -13°F (-25°C) to 115°F (+46°C)
Storage temperature: -13°F (-25°C) to 140°F (+60°C)
Relative humidity: 95% less than - non-condensing
Camera Sensor 0°: AIT Advanced Image Sensor
Camera Sensor 90°: AIT Advanced Image Sensor
Ergonomics: ± 90° rotatable display, alt. ±90° rotatable handle
Weight: 1.65Kg (+/- depending on probe diameter and working length)
Waterproof: Probe and distal End up to 1 bar- 10.2m H2O
Resistance: Probe and distal End to oils and saline (5%)
Probe diameter: 6.0mm or 4.0mm
Working length: 4.9ft (1.5m) - 24.6ft (7.5m)
Direction of view: 0° or 90°
Working distance: 10-50mm (6mm probe) or 4-20mm (4mm probe)
Articulation: 4-way
Resolution: 800x800px (6mm probe) or 400x400px (4mm probe)
Illumination Type: High-power LED on the TIP
Illumination control: 3 steps
Mission-Critical Applications Across Industries
The iX3D is not a one-size-fits-all tool; it is a precision instrument designed for industries where failure is not an option. Its advanced 3D measurement capabilities provide the quantitative data needed for critical maintenance, quality control, and safety decisions.
- Aerospace & Turbine EnginesAccurately measure the depth and volume of pitting, cracking, and erosion on high-pressure turbine blades. Use the 3D modeling feature to track defect progression over time, enabling predictive maintenance and preventing catastrophic failures.
- Manufacturing & Quality ControlInspect internal passages of complex castings for blockages, surface irregularities, or casting flash. Use the point-to-plane measurement to verify the flatness of critical mating surfaces without disassembling the component.
- Power Generation & EnergyQuickly identify and measure pitting, corrosion, and blockages within heat exchanger tubes. The 360° 3D model view enables a comprehensive assessment of the tube's internal condition.
- Automotive & CastingAnalyze cylinder walls for scoring, glazing, or cross-hatch pattern wear. The colored depth map provides an instant visualization of surface texture and condition, helping to diagnose issues like oil consumption or loss of compression.
- Oil & Gas, PetrochemicalUse the multi-point line measurement to create a detailed profile of a weld bead, identifying areas of undercut, lack of fusion, or improper reinforcement. The 3D data provides a permanent record for quality assurance and regulatory compliance.
- General NDTIdeal for any non-destructive inspection in confined, dark, or hazardous spaces — from hydraulics, heat exchangers, and gearboxes to welds, historical structures, lock mechanisms, and custom one-off challenges where disassembly is costly or impossible.
Tell us about your application and we will recommend you the right tool to do the job!
