Duct HVAC Camera
Air Duct inspection cameras for HVAC
Sign Up for Updates
Duct (HVAC) cleaning is an important part of maintaining good air quality in any building, if ducts are not being cleaned properly, air polluted by dust and other fine particles that can be harmful, will be circulated throughout the system. The best way to ensure ducts are being cleaned completely is to visually inspect them, this can now be accomplished using HVAC inspection cameras. These CCTV cameras are composed of a digital inspection camera attached to a push rod to enable the camera to access all parts of the duct work. With these HVAC cameras, small, normally inaccessible places in duct work can now be remotely visually inspected during and after cleaning to ensure a thorough job is done. Real time video of ducts can be seen by cleaning professionals and be shown to customers using a HVCA dust inspection camera, allowing them to appreciate the state of duct work before and after cleaning. Using a dust camera will also ensure dusts are properly and completely cleaned the first time. Proper use of a HVAC camera system will save you and your customers, time, effort, and money, and increase your productivity.
- Locate areas where debris has built up in duct work
- Ensure ducts are completely free of debris after cleaning
- Inspect new duct work
- Locate problem areas in existing duct work
All kinds of portable inspection devices now available on the market, semi rigid borescopes (aka Snake Cameras) are very popular and Medit's Voyager scope can be used for duct inspection as well. If you're looking for better quality picture and more remote access (up to 40 meter) Viper or Viper-S portable push cameras would be the best choice. You can also check out our Anaconda Pan-and-Tilt camera if you need as more visual access and maneuvering as possible. Contact our sales specialist to ensure you find the right camera to fit your needs for the best value.
- view nowStarting at$1,190.00
Push Camera "Viper"- Ø 38mm (1.5”) detachable camera head
- Working Length – 20 meter(65.6'), 35 meter (114.9 foot) and 40 meter(131.2')
- CCD camera with sapphire glass lens
- Built-in digital video recorder
- 7” TFT LCD Display in a waterproof case
- Image (JPEG )/Video (AVI) file capture
- Video output to a TV monitor
- Files capture onto a SD memory card
- 8 super white LED lights
Insertion Probe
• Length: 20 meter(65.6'), 35 meter (114.9 foot) and 40 meter(131.2')
• Diameter: 36mm (1.4")
• Color CCD camera with sapphire glass lens
• No articulation
• Fiberglass cable
• 60° Field of View (FOV)
• 0° Direction of view (DOV)
• Waterproof design for portable use
• Illumination: 8 white LEDs
• Special gold point touch connector to camera
Image Hub
• 7” Color LCD monitor with Video output, file playback
• Monitor Picture Resolution: 320 (TV Lines)
• SD memory card slot
• Recording format - AVI
• IR remote control
• Power adaptor: 110~240VAC, 12VDC/1800mA
• Rechargeable battery for portable use up to 3.5 hours
• Li-ion battery box (4400mAh)
• System Operating Temperature: -20°to 120°F
• Operating temperature - 20°F~ 120°F (- 28C°~ 50°C)1-877-613-2210 - view nowStarting at$899.00
"Orion II" Video Borescope- Ø from 4mm (0.16”) to 10mm (0.44”)
- Working Lengths from 1 meter (3.3 foot) to 30 meters (98 foot)
- Fast (up to 60 fps), High Resolution CMOS video camera chip
- 3.5” Color LCD Display, with 720x480 pixel resolution
- Image (JPEG )/Video (MPEG4) File capture
- AV output (PAL/NTSC selectable)
- 2 GB SD card for file capture/storage
- USB port (1.1/2.0) to transfer data to a PC
- LED Illumination, with variable intensity adjustment
- Working temperature -20° to +60° C
Insertion probe
• Diameter: 5.5mm (0.22")
• Length: OPTIONAL 1M (3.3'), 2M (6.5'), 3M (9.8') or 10M (33'), 20M (66'), 30M (98')
• Articulation: no articulation
• CMOS Image Sensor Resolution
• Resolution 720(H)*480(V)
• 67° Field of View (FOV)
• 0°Direction of view
• 1cm-8cm Focal range
• Waterproof insertion tube only (IP57)
• Light Source: 4-6 White LEDs
Imaging Hub
• 3.5”TFT LCD Monitor 320*240 Pixels
• Interface: Mini usb 1.1/ AV out/ Av in/
• MPG4(saved as AVI) Compression Format
• JPEG Still Image Storage Format
• TV system: NTSC & PAL
• Power:DC5V
• Battery: Rechargeable Li-Polymer Battery (3.7V)
• Language: 16 Languages1-877-613-2210 - view nowStarting at$349.00
Snake Scope "Voyager"- Cost effective Snake Scope
- Ø 5.5mm(0.22in) and 9.5mm(0.37in) insertion probes
- Working lengths: 1 meter (3.3ft), 2 meter(6.5ft), or 3 meter(9.8ft)
- CMOS Video Camera chip: 1/5” or 1/6”
- Image (JPEG )/Video (AVI) file capture
- Interface: SD Card, USB 1.1, RGB Video output
- Adjustable Handle and Screen positions
Insertion Probe
• Diameters: 5.5mm (0.22”) or 9.5mm(0.37")
• Length: 1M(3.3'), 2M(6.5'), 3M(9.8’)
• No articulation
• 1/5” or 1/6” CMOS chip
• Resolution (Dynamic/static) 320x240/ 720x480
• 67° Field of View (FOV)
• 0° Direction of view (DOV)
• 2cm~ 28cm (0.8” – 11”) Focal range
• Waterproof probe only
• 4 White LED (0~275 Lux/ 4cm)
• Lightness manual adjustment way: Yes
• Zoom: 5x Variable Digital Zoom
Image Hub
• 3.5” TFT LCD Monitor 320x 240 Pixels
• Interface: Mini-usb 1.1/ AV out
• Video storage format: AVI(320x240)
• Image storage format: JPEG(720x480)
• TV system: NTSC & PAL
• Power: 4AA Alkaline type Batteries
• Recording Format: SD Memory Card (Up to 32GB SDHC capacity)
• Adjustable Hand piece: Monitor moves upright, or down to rest along the handle
• Carry Case: 40 x 33x 12cm1-877-613-2210
